Switched Inductors: Building Blocks: With insight & intuition - Brossura

Rincón-Mora, Gabriel Alfonso

Brossura

ISBN 13: 9798541373233

Casa editrice: Independently published, 2021

Riassunto

Switched-inductor power supplies are microelectronic systems with analog, analog–digital, and digital functions that set, manage, and control their outputs. This 49-page handbook shows how to implement and design the building blocks needed for this functionality. Some of the blocks covered are current and voltage sensors, hysteretic and summing comparators, sawtooth generators and one-shot oscillators, gate drivers and dead-time logic, zero-current detectors, ring suppressors, switched diodes, and shutdown and starter functions. The material also reviews the circuits used to realize some of these blocks, like low- and high-side supply-sensing comparators, push–pull logic, class-A inverters, set–reset flip flops, and others. Illustrative figures, equations, and examples complement discussions throughout.

Dettagli dell?edizione

• Editore: Independently published
• Data di pubblicazione: 2021
• Lingua: Inglese
• ISBN 13: 9798541373233
• Rilegatura: Copertina flessibile
• Numero di pagine: 64
• Contatto del produttore: non disponibile
